Hoist PROCAT 1200, 990 kg

Electric hoist with a pulling force of 990 kg. Especially suitable for use in warehouses and closed premises. It has a 12 m steel rope. Thanks to a special device, this rope can be used as a double rope. Thus, the load capacity increases from 600 kg to 990 kg. High-quality mechanisms and overload protection guarantee that the device will work long and reliably. The rolling speed of the PROCAT 1200 hoist is 8 m/min, and when used with a double rope – 4 m/min. The hoist is mounted on a steel beam, whose diameter must be 6.8 – 9.4 cm, with a minimum height of 11 cm. Curves for the PROCAT 1200 hoist do not pose a problem, if the radius of the curves is greater than 1 m.

PROCAT 1200 hoist features

• Simple and quick operation and installation
• Electric motor with 1800W power
• Cruising speed 13 m/min
• Electric power supply 230V | 2.2A
• IP 20 protection class
• Min. turning radius 1 m
• Automatic engine stop when the end of the rope is reached

Requirements for steel beams:

Steel profile: wide beam flange, I-beam, or double-T beam

Height: h = 110 mm

Width: b = 68 - 94 mm

Package includes:

• PROCAT 1200 hoist / trolley combination
• Pulley with hook
• Instructions

• 24 months warranty for the tool
